*304 Stainless Steel
*Bi-direction
*Compatible with all kinds of access control system
*Use for outdoor and indoor
*Anti-pinch, anti-collision
Framework | 304 Stainless Steel | ||||
Dimensions | 480*280*990 | ||||
Arm length | 600-900mm | ||||
Passage width | 1200mm | ||||
Dry Contact | 12V | ||||
LED indicating light | One | ||||
Card-reading window: | Two | ||||
Rated power | 120W | ||||
Operating temperature | -25℃ ~ +60℃, RH ≤90% | ||||
Related humidity | ≥90%RH | ||||
Comunication Interface | RS485,distance ≤1200m | ||||
Power supply | AC 220V/110V ±10% 50/60MHZ (optional) | ||||
OpeningTransit speed: | 30-45persons per minute | ||||
Closing Transit speed: | 25-35per minute | ||||
1. working method can be set by the buttons on the main panel
2. Anti-pinch, anti-collision. If there is block during return of gate, motor stops working automatically. Reset again after a default delay, the force 2Kg.
3.Anti-illegal in, anti-intrusion, auto close for reverse direction.
4. Anti-collision, gate closes when no valid signal is given.
5. Protection functions for gate, gate open to prevent motor from being damaged if there is outer force collision.
6. Gates can be synchronous
7.Auto-reset. If not go through in a preset time, pass right would be cancelled automatically. (1-60s adjustable), default time is 10s.
8. Reset function by photocells, 4 or 6 pairs.
9. Anti-pinch function by photocells, 4 pairs
10.Compatible with Access control system, consumption system, ESD system, E-ticket system and so on.
11. One way or two way control
12. Unit can be controlled and administered by remote control
13. Led lamp indicator
